LIFTING - CALDWELL Model 33

Model 33_singlePG_ 033119 copy-1 copy.jpg

Two & Four Point Modular Spreader Beam Systems

Model 33_singlePG_ 033119 copy-2 copy.jpg

Two & Four Point
Spreader Beam Systems

Caldwell’s lifting solutions are considerable with its two and four point Spreader Beam Systems. Caldwell can supply you with a spreader lifting system that fits your project every time! By the use of various spreader pipe sections, end or corner fittings, your lifter configurations are virtually limitless. Caldwell spreader systems are easy to transport to the job site and assemble. Once the job is completed you can save on storage space by disassembling the beam and store away safely until your next job. This allows you to use
components over and over instead of purchasing a new
spreader beam for every project!


Our experienced application specialists and design
engineers are constantly developing new lifting
solutions to ensure you have lifting products that
meet your needs. All of Caldwell’s spreader
products comply with ASME B30.20, BTH-1,
Design Category B specifications. Caldwell’s two
point and four point spreader systems offer
impressive strength-to-weight ratio that makes
them easy to handle on the job site.


Caldwell has been your industry leader in
below-the-hook lifting solutions since 1954.
Caldwell is the place to find the custom
solutions you need. We have over 200
design styles and thousands of standard
models available as well.


Not sure which product is right for
your job? Call us, we’ll be glad to
help and lift you up!

Model 33_singlePG_ 033119 copy-3 copy.jpg

Model 33 - 30 Metric Ton

Four Lifting Point Spreader Beam System
Caldwell’s 30 Ton Bolted Modular Spreader Beam can be configured in spreads of 3 to 19 feet in square or rectangular configurations.


Features:

  • Quickly configure a 4-point spreader beam to match your lift requirements.

  • 4-point spreader beam provides added stability.

  • Knock-down design is easily transported.

  • Complies with ASME standards.

  • Combinations of 1 to 5 spreader sections can be used to create custom square and rectangular configurations.

  • Custom designed systems available.

  • Additional spread lengths and sizes coming.

Two Lifting Point Spreader Beam System
Caldwell’s 24 ton Bolted Modular Spreader beam can be configured in spreads of 3 to 26 feet.


Features:

  • Quickly configure a spreader beam to match your lift requirements.

  • Knock-down design is easily transported.

  • Unique pivoting drop link.

  • ​

  • Complies with ASME standards.

  • Combinations of 1 to 5 spreader sections can be used to create custom spreader beam lengths.

  • Custom designed systems available.

  • Additional spread lengths and sizes coming.

Two Lifting Point Spreader Beam System
Caldwell’s 50 ton Bolted Modular Spreader beam can be configured in spreads of 3 to 42 feet.


Features:

  • Quickly configure a spreader beam to match your lift requirements.

  • Knock-down design is easily transported.

  • Unique pivoting drop link.

  • Complies with ASME standards.

  • Combinations of 1 to 5 spreader sections can be used to create custom spreader beam lengths.

  • Custom designed systems available.

  • Additional spread lengths and sizes coming.

Model 33 - 24 Metric Ton

Model 33 - 24 Metric Ton

Two & Four Point
Spreader Beam Systems

Model 33_singlePG_ 033119 copy-4 copy.jpg

Model 33 - 110 Metric Ton

Two Lifting Point Spreader Beam System
Caldwell’s 110 Ton Bolted Modular Spreader Beam can be configured in spreads of 6 to 59 feet.


Features:

  • Quickly configure a spreader beam to match your lift requirements.

  • Knock-down design is easily transported.

  • Unique pivoting drop link.

  • Complies with ASME standards.

  • Combinations of 1 to 6 spreader sections can be used to create custom spreader beam lengths.

  • Custom designed systems available.

  • Additional spread lengths and sizes coming.

Four Lifting Point Spreader Beam System
Caldwell’s 60 Ton Bolted Modular Spreader Beam can be configured in spreads of 3 to 19 feet in square or rectangular configurations.


Features:

  • Quickly configure a 4-point spreader beam to match your lift requirements.

  • 4-point spreader beam provides added stability.

  • Knock-down design is easily transported.

  • Complies with ASME standards.

  • Combinations of 1 to 5 spreader sections can be used to create custom square and rectangular configurations.

  • Custom designed systems available.

  • Additional spread lengths and sizes coming.

Two Lifting Point Spreader Beam System
Caldwell’s 70 Ton Bolted Modular Spreader Beam can be configured in spreads of 3 to 45 feet.


Features:

  • Quickly configure a spreader beam to match your lift requirements.

  • Knock-down design is easily transported.

  • Unique pivoting drop link.

  • Complies with ASME standards.

  • Combinations of 1 to 5 spreader sections can be used to create custom spreader beam lengths.

  • Custom designed systems available.

  • Additional spread lengths and sizes coming.

Model 33 - 60 Metric Ton

Model 33 - 70 Metric Ton

Model 33_singlePG_ 033119 copy-5 copy.jpg

Model 33 - 60 Metric Ton

Model 33 - 70 Metric Ton

Four Lifting Point Spreader Beam System
Caldwell’s 60 Ton Bolted Modular Spreader Beam can be configured in spreads of 3 to 19 feet in square or rectangular configurations.



Features:

• Quickly configure a 4-point spreader beam to match your lift requirements.

• 4-point spreader beam provides added

stability.

• Knock-down design is easily transported.

• Complies with ASME standards.

• Combinations of 1 to 5 spreader

sections can be used to create

custom square and rectangular

configurations.

• Custom designed systems

available.

• Additional spread

lengths and sizes

coming.

Two Lifting Point Spreader Beam System
Caldwell’s 70 Ton Bolted Modular Spreader Beam can be configured in spreads of 3 to 45 feet.


Features:

• Quickly configure a spreader beam to match your lift requirements.

• Knock-down design is easily

transported.

• Unique pivoting drop link.

• Complies with ASME standards.

• Combinations of 1 to 5 spreader

sections can be used to create

custom spreader beam

lengths.

• Custom designed systems

available.

• Additional spread

lengths and sizes

coming.

Two Lifting Point Spreader Beam System
Caldwell’s 110H Ton Bolted Modular Spreader Beam can be configured in spreads of 6 to 59 feet.


Features:

  • Quickly configure a spreader beam to match your lift requirements.

  • Knock-down design is easily transported.

  • Unique pivoting drop link.

  • Complies with ASME standards.

  • Combinations of 1 to 6 spreader sections can be used to create custom spreader beam lengths.

  • Custom designed systems available.

  • Additional spread lengths and sizes coming.

Model 33 - 110H (167) Metric Ton

Model 33_singlePG_ 033119 copy-6 copy.jpg

Model 30HC

Model BEF

Two & Four Point
Spreader Beam Systems

High Capacity Spreader Beam
Caldwell’s High Capacity Spreader Beam is the solution
you need to fill those orders where a quick delivery is
required on beams with standard capacities ranging from
25 to 130 tons.

​

Features:
• Unique pivoting lower lugs allow for 75° to 90° lower
rigging angle.
• Beam assembly without rigging available in 7 - 10 days.
• Optional wire rope top rigging available.
• Complies with ASME standards.
• One two or three piece pipe
systems can be created using
couplings.
• Custom designed
systems available.

Medium Capacity Spreader Beam
Caldwell’s Medium Capacity Spreader beam is the
solution you need to handle an immediate requirement for
lift capacities with a range of 7.5 to 39 tons.


Features:
• Slot lugs allow for angled bottom rigging
• Beam assembly without rigging available 7-10-days
• Optional wire rope rigging available.
• Complies with ASME standards
• One, two or three piece pipe
systems can be created using
couplings.
• Custom designed
systems available.

Model 430 - DURA-LITE™

Composite Spreader Beam


Features:
• Lightweight.
• Non-Conductive.
• Corrosion Resistant.
• Complies with ASME B30.20, design

category B, service class 4.
• Proof tested with certificate
issued.
• DURA-LITE™ product is
compliant with European
Community standards CE.

Model 33_singlePG_ 033119 copy-7 copy.jpg

Model 34

Model 38

Special Spreader Systems
This series of special spreader systems can be designed to
lift loads of almost any size or weight. Certain adjustability
characteristics allow for a wide range of usage as well as
handling unbalanced loads where the center of gravity is
substantially off center.

Four Lifting Point Spreader Beam


Features:
• Knock-down design is easily transported.
• 6 or 9 ton capacity.
• Spreads up to 10’ x 10’.
• Four point spreader beam provides added stability.
• Chain top rigging and hoist rings.
• Lower lifting shackles standard.
• Complies with ASME standards.
• Custom designs available.

Model 33_singlePG_ 033119 copy-8 copy.jpg

Two & Four Point
Spreader Beam Systems

Model HC-BEF

High Capacity Beam End Fittings


Features:
• Build your own spreader beam.
• Pivoting lower lugs allow
for 75° to 90° lower rigging
angle.
• Complies with ASME
standards when assembled
to specifications using
designated pipe and rigging.

Model BEF

Spreader Beam End Fittings


Features:
• Build your own spreader beam.
• Designed to work with a range of
shackle sizes, both top and
bottom.
• Complies with ASME standards
when assembled to specifications
using designated pipe and rigging.

Model BEF-FSB

Beam End Fittings - Four Point Spreader Beam


Features:
• Build your own spreader beam.
• Designed to work with hoist rings
for flexibility.
• Complies with ASME standards
when assembled to specification
using designated pipe and rigging.

Model BEF-PC

Beam End Fitting Pipe Coupler


Features:
• Add flexibility to your spreader beam end fitting system.
• Securely joins two pipe lengths to
create a longer spreader beam.
• Innovative design reduces sag in
the spread system once assembled.
• Includes all connecting pin or bolts.
• Complies with ASME standards when assembled to specifications using designated pipe and rigging.
