LIFTING - RUD MAXI Assembly Kit

1-2 VIP-MAXI_Flyer_V1_en-1.jpg

MAXI ASSEMBLY KIT

FOR LOADS UP TO 126T


1-2 VIP-MAXI_Flyer_V1_en-2.jpg
1-2 VIP-MAXI_Flyer_V1_en-3.jpg

VIP >MAXI< Masterlinks 1/2-28 and VBK 1/2-28, for 1 resp. 2 leg.

VIP >MAXI< Shortening claw VV28 with securing against self-acting loosening.

VIP >MAXI< Connecting link for the connection with lifting points, shackles, chain etc.

VIP >MAXI< Round steel link chain 28 x 84, quality grade 10, extreme robust and wear resistant, pink powder coated.

VIP >MAXI< VCGH-28, proved and tested Cobra-clevis hook in skeletal light weight-design with a robust, forged safety latch

VIP >MAXI< End link VB-28, f.e. for chain coupler RS-VVS-28 or shackle connection VC-SCH 6.

The robust RUD-ID-EASY-CHECK® (readers) captures the identification number of the RUD-ID-Point® and transfers it via Bluetooth or USB into the RUD-ID-NET®-Applikation software resp. optionally into your PC-application (f.e. Wordpad, MS Word, MS Excel, SAP) etc.

The components can be marked with the RUD-ID-Point® (RFID-Chip) and allocated by a unique identification number

The expandable RUD-ID-NET®- application (software) supports you with the administration and documentation of your components.

1-2 VIP-MAXI_Flyer_V1_en-4.jpg

Unsymmetrical heavy load?
Different strand lengths?

Your ideal addition for your heavy load lifting means to connect wire rope or synthetic round sling with the MAXI-Vario-strand

1-2 VIP-MAXI_Flyer_V1_en-5.jpg

* VAK 1/2-28: For single crane hooks (Size 40+50) and double crane hooks (Size 40+50)

** VBK 1/2-28: For single crane hooks (Size 12-32) and double crane hooks (Size 12-32)

*** In preparation

 For details see Lifting point catalogue

Assembly kit

1-2 VIP-MAXI_Flyer_V1_en-6.jpg

Important hints:

■ At unsymmetrical loads the WLL must be reduced by 50 %.

■ *Choke hitch or endless chains:

  • With bitts, bolts, resp. diameter of shackle pin > 3 x t (250 mm) the WLL of a double strand can be assumed.

  • With smaller diameters (loading at the edge) the WLL must be reduced by 20 %

When using a basket hitch it must be guaranteed that loads cannot shift into dangerous positions or drop (BetrSichV, Attachment 1 acc. to § 7).
